| Model |
LX A5.0-30 |
| Battery Type |
LFP (LiFePO4) |
| Nominal Battery Energy |
5.12kWh |
| Usable Energy |
5kWh |
| Operating Voltage Range |
43.20V ~ 58.24V |
| Nominal Charge Current |
60A |
| Max Continuous Charge Current |
90A |
| Nominal Discharge Current |
100A |
| Max Continuous Discharge Current |
150A |
| Max Pulse Discharge Current |
<200A (30s) |
| Max Continuous Discharge Power |
7200W |
| Discharge Rate |
1.5C |
| Communication |
CAN |
| Round-trip Efficiency |
≥96% |
| Cycle Life |
6000 Cycles @ 25°C, 0.2C, 70%EOL |
| Operating Temperature |
Charge: 0°C ~ 55°C, Discharge: -20°C ~ 55°C |
| Max Storage Time |
12 Months (Maintenance-free) |
| Max Operating Altitude |
4000m |
| Weight |
44 KG |
| Dimensions (Core Part) |
442 × 133 × 520 mm |
| Dimensions (Maximum) |
483 × 133 × 559 mm |
| Protection Rating |
IP20 |
| Applications |
On-Grid / On-Grid + Backup / Off-Grid |
| Scalability |
Up to 30 Units Parallel (150kWh) |
| Mounting Methods |
19-inch Rack / Floor / Wall Mount |
| Safety Certifications |
IEC62619, IEC63056, N140 |
| EMC Standards |
EN IEC 61000-6-1 / 6-2 / 6-3 / 6-4 |
| Transportation Certification |
UN38.3, ADR |
| Environmental Standard |
ROHS |
